T-14 Trench Drains

PEDESTRIAN RATED

Evergrate T-14 series trench drain is commonly used as an inlet for street flow to enter bioretention and infiltration features. With a wide drainage area and low profile, T-14 trench drain is combines with Evergrate curb opening castings for a durable, attractive Low Impact Design (LID) feature. Evergrate trench drain products are Made in the USA from recycled content.

Get a Quote

drawings

*CAD drawings available upon request

Angle Frame

Angle Frame Design of T-14 Trench Drain
Product Drawing of T-14A Metro Trench Drain

T-14A Metro

Product Drawing of T-14A Continuum Trench Drain

T-14A Continuum

Product Drawing of T-14A Tsunami Trench Drain

T-14A Tsunami

Product Drawing of T-14A SolidTrench Drain

T-14A Solid

Channel Frame

Product Drawing of T-14 Trench Drain
Product Drawing of T-14C Metro Trench Drain

T-14C Metro

Product Drawing of T-14C Continuum Trench Drain

T-14C Continuum

Product Drawing of T-14C Tsunami Trench Drain

T-14C Tsunami

Product Drawing of T-14C SolidTrench Drain

T-14C Solid

Features

ADA Compliance

ADA Compliance

Grate design conforms to ADA Accessibility Guidelines for pedestrian areas

Ideal Sidewalk Drainage Solution

Ideal Sidewalk Drainage Solution

Combines with Evergrate downspout and curb opening products for complete drainage system

Theft Resistant Design

Theft Resistant Design

Stainless steel Penta-Lock mechanism prevents theft while allowing grate removal for maintenance

Various Grate Styles Available

Various Grate Styles Available

4 versatile designs including 1 solid cover: Metro, Continuum, Tsunami, Solid Cover

Manufactured from Recycled Content

Manufactured from Recycled Content

Cast iron grates consist of 74.5% pre-consumer and post-consumer recycled content

Optional Powder Coat Finish

Optional Powder Coat Finish

Choose from 6 standard colors for high quality, durable powder coat finish

Accommodates Custom Trench Lengths

Accommodates Custom Trench Lengths

Frame material is fabricated to length, custom grate lengths available

Made in USA

Made in USA

All components proudly manufactured and assembled in the USA

Green Infrastructure Solution

Green Infrastructure Solution

Ideal for green infrastructure and Low Impact Design (LID) applications

Available in variety of sizes

Available in variety of sizes

Low Slope Drainage Solution Description: Low profile trench frame and grate allow positive slope with minimal natural gradient.
